Telco SSR02-07012805H-AC2-DP2-0.5-J12

SKU: SSR02-07012805H-AC2-DP2-0.5-J12
Product Normally Ships in 5-7 Business Days
Call Us for Volume Discount Availability 704.519.4661
$1,347.18

SPACESCAN RECEIVER, 18-30VDC, ANALOG OUTPUT: 4-20mA / 0-10V (2 WIRE), 2 x PNP, 0-10M RANGE, 640MM ACTIVE HEIGHT, BEAMS: 128/382, CH SPG: 5MM, 0.5M CABLE 12P M12 QD
  • Sensing Range 0–10 m
  • Features Blanking, Cross Parallel Beams Selectable, Hole Detection, On Off Delay, Programmable Geometrical Analysis, RS-485, Smoothing
  • Active Height 640 mm
  • Channel Spacing 5 mm
  • Channel Count 128
  • Parallel Beam Count 128
  • Cross Beam Count 382
  • Supply Voltage 18 to 30 V DC
  • Output 0 to 10 V, 4 to 20 mA, PNP
  • Output State NC, NO
  • Controls Automatic Sensitivity Adjustment, Hysteresis Adjustment, Manual Sensitivity Adjustment
  • Operating Modes Through Beam
  • Housing 33 × 36 mm
  • Housing Material Aluminum
  • Housing Length 700 mm
  • Connection M12 Plug With Pigtail
  • Pin Count 12
  • Cable Length 0.5 m
  • Protection Rating IP67
  • Operating Temperature Range −30 to +60 °C
