Home » Telco SMP7401-IO-TSJ
Telco Sensors

Telco SMP7401-IO-TSJ

SKU: SMP7401-IO-TSJ
Product Normally Ships in 5-7 Business Days
Call Us for Volume Discount Availability 704.519.4661
$388.54

PROXIMITY SENSOR, STAINLESS, M18, NPN, WITH IO LINK, M12 QD, 4 PIN, STAINLESS
  • Sensing Range 0–1 m
  • Light Source Infrared 880 nm
  • Response Time 2 ms
  • Switching Frequency 250 hz
  • Features IO-Link
  • Supply Voltage 10 to 30 V DC
  • Output NPN, Push-Pull
  • Maximum Load Current 200 mA
  • Controls Light Dark Selection, Sensitivity Adjustment
  • Operating Modes Dark Operated, Diffuse Proximity, IO-Link Configurable, Light Operated, Selectable
  • Housing M18 × 1
  • Housing Material Stainless Steel
  • Connection M12 Plug
  • Pin Count 4
  • Protection Rating IP67
  • Operating Temperature Range −20 to +60 °C
