Telco SGP30-125024A1M09-0.5-J5

SKU: SGP30-125024A1M09-0.5-J5
Product Normally Ships in 5-7 Business Days
Call Us for Volume Discount Availability 704.519.4661
$1,079.29

DIFFUSE PROXIMITY LIGHT CURTAIN, 12-30VDC, 0-1.3M RANGE, NC(DO), ACTIVE HEIGHT: 1065MM, CHANNELS:24, CH SPG: 46MM, 0.5M CABLE 5P M12 QD
  • Sensing Range 0–1.3 m
  • Light Source Infrared 880 nm
  • Ambient Light Immunity 100,000 lux at 5° incidence
  • Opening Angle ±10°
  • Response Time 26 ms
  • Features Blanking, Output Indicator, Power indicator, System status indicator, Short-circuit protection, Reverse-polarity protection
  • Active Height 1065 mm
  • Channel Spacing 46 mm
  • Channel Count 24
  • Supply Voltage 12 to 30 V DC
  • Output Solid-State Relay
  • Output State NC
  • Maximum Load Current 200 mA
  • Maximum Current Consumption 120 mA RMS
  • Controls Sensitivity Adjustment
  • Operating Modes Dark Operated, Diffuse Proximity
  • Housing 23.4 × 30.9 mm
  • Housing Material Aluminum
  • Housing Length 1250 mm
  • Connection M12 Plug With Pigtail
  • Pin Count 5
  • Cable Length 0.5 m
  • Cable Material PVC
  • Front Lens Material Polycarbonate
  • Protection Rating IP67
  • Operating Temperature Range −30 to +60 °C
