Telco OAS-100-P2S-T3

SKU: OAS-100-P2S-T3
Product Normally Ships in 5-7 Business Days
Call Us for Volume Discount Availability 704.519.4661
$1,500.76

OPTICAL FRAME SENSOR, 24VDC, PNP, NO, W 100mm x D 94mm
  • Light Source Infrared 880 nm
  • Ambient Light Immunity Over 50,000 lux
  • Hysteresis Less Than 0.2 mm
  • Response Time 0.1 ms
  • Switching Frequency 5000 hz
  • Features Output Indicator
  • Resolution 2 mm
  • Opening Width 100 mm
  • Opening Depth 94 mm
  • Supply Voltage 24 V DC
  • Output PNP
  • Output State NO
  • Maximum Load Current 200 mA
  • Maximum Current Consumption 70 mA
  • Controls Pulse Time Adjustment, Sensitivity Adjustment
  • Operating Modes Through Beam
  • Housing Material Aluminum
  • Connection M8 Plug
  • Pin Count 3
  • Sensing Face Material PMMA
  • Protection Rating IP67
  • Operating Temperature Range −20 to +60 °C
