P-0D1 / P-0E1 — Threaded Hex Shaft Mounting Brackets

SKU: P-0D1-P-0E1
Please contact us for assistance with part number configuration and compatibility at 704-519-4661 or fill out a Request for Quote below

P-0D1 (hex flat up) and P-0E1 (hex point up) are threaded hex shaft mounting brackets designed for the Itoh Denki PM635 family of heavy-duty Power Moller® DC pallet handling rollers. These low profile brackets are engineered for maximum holding strength on the larger 11/16" threaded hex shafts used on PM635 models.

Each bracket is supplied with an M20 x 1.25 nut. One bracket is required per PM635 roller (cable side mounting).

Key Details

  • P-0D1: Hex flat up orientation
  • P-0E1: Hex point up orientation
  • Low profile design for maximum holding of threaded hex shafts
  • Supplied with M20 x 1.25 nut
  • Designed for 11/16" hex shafts

Installation

  • Thrust collar nuts must be torqued to 110.6 lb•ft ±10% (149.5 Nm)
  • 1 bracket required per PM635 roller
  • Brackets are included with PM635 roller purchase

Compatible Rollers

  • PM635FS
  • PM635KE
  • PM635KT

Dimensions

  • Overall: 60 mm x 34.6 mm [2.36" x 1.36"]
  • Width: 43 mm [1.69"]
