Dorner FMZ099LDS423EN FlexMove Gearmotor, Fixed Speed or VFD, Direct Mount SEW, Left Hand, 0.25 kW, 13 RPM

Dorner FlexMove direct mount SEW SA37-size gearmotor, left-hand, for FlexMove direct-drive units ordered with a 20 mm drive shaft. Rated for fixed-speed operation or variable-speed operation with a VFD.

0.25 kW (0.33 Hp), 13 RPM, 71 Nm, 230/400 V, 3 phase, 50 Hz, 1.3 / 0.76 A.

Chain speed at 50 Hz: 5.2 m/min (17.1 ft/min) on FK, FS, FM, FU and FV systems; 5.5 m/min (18 ft/min) on FC and FL systems.

Sealed, totally enclosed fan-cooled. Wiring by others. Left-hand gearmotors match left-hand drive units. When buying a gearmotor without a starter, supply your own on/off switch and motor overload protection.
