Dorner FMZ029LSS423EN FlexMove Gearmotor, Fixed Speed or VFD, Suspended Mount SEW, Left Hand, 0.55 kW, 48 RPM

Dorner FlexMove suspended mount SEW SA37-size gearmotor, left-hand, for FlexMove suspended-drive units ordered with a 20 mm drive shaft. Rated for fixed-speed operation or variable-speed operation with a VFD.

0.55 kW (0.75 Hp), 48 RPM, 54 Nm, 230/400 V, 3 phase, 50 Hz, 2.6 / 1.52 A.

Chain speed at 50 Hz: 19.3 m/min (63.3 ft/min) on FK, FS, FM, FU and FV systems; 20.3 m/min (66.6 ft/min) on FC and FL systems.

Sealed, totally enclosed fan-cooled. Wiring by others. Left-hand gearmotors match left-hand drive units. When buying a gearmotor without a starter, supply your own on/off switch and motor overload protection.
