Dorner FMZ013RDS423EN FlexMove Gearmotor, Fixed Speed or VFD, Direct Mount SEW, Right Hand, 0.75 kW, 104 RPM

Dorner FlexMove direct mount SEW SA37-size gearmotor, right-hand, for FlexMove direct-drive units ordered with a 20 mm drive shaft. Rated for fixed-speed operation or variable-speed operation with a VFD.

0.75 kW (1 Hp), 104 RPM, 41 Nm, 230/400 V, 3 phase, 50 Hz, 3.1 / 1.79 A.

Chain speed at 50 Hz: 41.8 m/min (137.1 ft/min) on FK, FS, FM, FU and FV systems; 44.1 m/min (144.7 ft/min) on FC and FL systems.

Sealed, totally enclosed fan-cooled. Wiring by others. Right-hand gearmotors match right-hand drive units. When buying a gearmotor without a starter, supply your own on/off switch and motor overload protection.
