Dorner FMZ009RSS423EN FlexMove Gearmotor, Fixed Speed or VFD, Suspended Mount SEW, Right Hand, 1.1 kW, 156 RPM

Dorner FlexMove suspended mount SEW SA37-size gearmotor, right-hand, for FlexMove suspended-drive units ordered with a 20 mm drive shaft. Rated for fixed-speed operation or variable-speed operation with a VFD.

1.1 kW (1.5 Hp), 156 RPM, 38 Nm, 230/400 V, 3 phase, 50 Hz, 4.1 / 2.38 A.

Chain speed at 50 Hz: 62.7 m/min (205.7 ft/min) on FK, FS, FM, FU and FV systems; 66.1 m/min (213.9 ft/min) on FC and FL systems.

Sealed, totally enclosed fan-cooled. Wiring by others. Right-hand gearmotors match right-hand drive units. When buying a gearmotor without a starter, supply your own on/off switch and motor overload protection.
