Dorner FMZ007RSS423EN FlexMove Gearmotor, Fixed Speed or VFD, Suspended Mount SEW, Right Hand, 1.5 kW, 216 RPM

Dorner FlexMove suspended mount SEW SA37-size gearmotor, right-hand, for FlexMove suspended-drive units ordered with a 20 mm drive shaft. Rated for fixed-speed operation or variable-speed operation with a VFD.

1.5 kW (2 Hp), 216 RPM, 42 Nm, 230/400 V, 3 phase, 50 Hz, 5.6 / 3.23 A.

Chain speed at 50 Hz: 86.8 m/min (284.8 ft/min) on FK, FS, FM, FU and FV systems; 91.6 m/min (300.5 ft/min) on FC and FL systems.

Sealed, totally enclosed fan-cooled. Wiring by others. Right-hand gearmotors match right-hand drive units. When buying a gearmotor without a starter, supply your own on/off switch and motor overload protection.
