Home » Telco SSR02-24612020HC-AC2-DN2-10
Telco Sensors

Telco SSR02-24612020HC-AC2-DN2-10

SKU: SSR02-24612020HC-AC2-DN2-10
Product Normally Ships in 5-7 Business Days
Call Us for Volume Discount Availability 704.519.4661
$2,146.48

SPACESCAN RECEIVER, 18-30VDC, ANALOG OUTPUT: 4-20mA / 0-10V (2 WIRE), 2 x NPN, 0-10M RANGE, 2385MM ACTIVE HEIGHT, BEAMS: 120/358, CH SPG: 20MM, 10M CABLE
  • Sensing Range 0–10 m
  • Features Blanking, Cross Parallel Beams Selectable, Hole Detection, On Off Delay, Programmable Geometrical Analysis, RS-485, Smoothing
  • Active Height 2385 mm
  • Channel Spacing 20 mm
  • Channel Count 120
  • Parallel Beam Count 120
  • Cross Beam Count 358
  • Supply Voltage 18 to 30 V DC
  • Output 0 to 10 V, 4 to 20 mA, NPN
  • Output State NC, NO
  • Controls Automatic Sensitivity Adjustment, Hysteresis Adjustment, Manual Sensitivity Adjustment
  • Operating Modes Through Beam
  • Housing 33 × 36 mm
  • Housing Material Aluminum
  • Housing Length 2460 mm
  • Connection Integral Cable
  • Cable Length 10 m
  • Protection Rating IP67
  • Operating Temperature Range −30 to +60 °C
