Home » Telco SSR02-18208820H-ANN-DP4-0.5-J12
Telco Sensors

Telco SSR02-18208820H-ANN-DP4-0.5-J12

SKU: SSR02-18208820H-ANN-DP4-0.5-J12
Product Normally Ships in 5-7 Business Days
Call Us for Volume Discount Availability 704.519.4661
$1,617.61

SPACESCAN RECEIVER, 18-30VDC, 4 x PNP, 0-10M RANGE, 1745MM ACTIVE HEIGHT, BEAMS: 88/262, CH SPG: 20MM, 0.5M CABLE 12P M12 QD
  • Sensing Range 0–10 m
  • Features Blanking, Cross Parallel Beams Selectable, Hole Detection, On Off Delay, Programmable Geometrical Analysis, RS-485, Smoothing
  • Active Height 1745 mm
  • Channel Spacing 20 mm
  • Channel Count 88
  • Parallel Beam Count 88
  • Cross Beam Count 262
  • Supply Voltage 18 to 30 V DC
  • Output PNP
  • Output State NC, NO
  • Controls Automatic Sensitivity Adjustment, Hysteresis Adjustment, Manual Sensitivity Adjustment
  • Operating Modes Through Beam
  • Housing 33 × 36 mm
  • Housing Material Aluminum
  • Housing Length 1820 mm
  • Connection M12 Plug With Pigtail
  • Pin Count 12
  • Cable Length 0.5 m
  • Protection Rating IP67
  • Operating Temperature Range −30 to +60 °C
