GCKW-25GH106NCN-SR03 — CKD GCKW Electric Actuator, Compact Gripper
Call Us for Volume Discount Availability 704.519.4661
Regular price
$1,734.31
Couldn't load pickup availability
- Manufacturer Catalog Download
Stepper actuator, compact gripper type, size 25, 6 mm stroke, side connector, movable 3m
| Model Number | GCKW-25GH106NCN-SR03 |
| Series | GCKW |
| Size | 25 |
| Stroke | 6 |
| Connector Direction | Side Connector |
| Relay Cable | Movable 3m |
| Encoder | Incremental encoder |
| Compatible Controller | ECMG/ECG-B |
| Weight | 1.08 kg |
| Dimensions (V × W × H) | 121.0 × 48 × 52.5 mm |
