Del-Tron Precision DL20-DW-145-SV-C DL20 Series Linear Actuators
Call Us for Volume Discount Availability 704.519.4661
Regular price
$1,125.00
Couldn't load pickup availability
All dimensions in millimeters unless otherwise specified
Servo Motor (SV) Yaskawa SGMAH
| Model # | DL20-DW-145-SV-C |
|---|---|
| OAL | 248.8 |
| L | 191.0 |
| A | 40.8 |
| B | 42.0 |
| C | 32.5 |
| D | 7.1 |
| E | 30.0 |
Performance Specifications
| Load Capacity (N) | 200 |
|---|---|
| Positioning Accuracy (µm) | 50 |
| Coefficient of Friction | 0.01 |
| Positional Repeatability (µm) | 4 |
| Running Parallelism (µm) | 15 |
| Backlash (µm) | zero |
| Linear Speed (mm/sec) | 100 |
| Sensor | None |
